Model | F1 Roadcar | F1 GTR Racecar | F1 LM Roadcar |
Year of production | 1993-98 | 1995 | 1996 |
Examples built | 64 | 9 | 5 |
Engine | BMW V12 | BMW V12 | BMW V12 |
Cubic Capacity | 6064 cc | 6064cc | 6064cc |
Engine Management | TAG 3.12 Ignition/Injection | TAG 3.12 Ignition/Injection | TAG 3.12 Ignition/Injection |
Power output (bhp) | 627 | 600 | 680 |
Transmission | Transverse 6-speed Limited Slip Differential | Aluminium case transverse 6-speed, LSD | Transverse 6-speed Racing Unit, LSD |
Chassis | Carbon fibre reinforced composite monocoque | Carbon fibre reinforced composite monocoque | Carbon fibre reinforced composite monocoque |
Body | Carbon fibre composite panels | Carbon fibre composite panels | Carbon fibre composite panels |
Front Suspension | Double wishbones, Ground Plane Sheer centre sub-frame light alloy damper/co-axial coil spring, anti-roll bar | Double wishbones, light alloy damper/co-axial coil spring, anti-roll bar | Double wishbones, light alloy damper/co-axial coil spring, anti-roll bar |
Rear suspension | Double wishbones, Inclined Axis Sheer mounting, light alloy damper/coaxle coil spring, toe-in/toe-out control links | Double wishbones, light alloy damper/coaxle coil spring | Double wishbones, light alloy damper/coaxle coil spring |
Brakes F/R | Outboard 13/12in ventilated discs | Outboard 15/14in ventilated carbon discs | Outboard 13/12in ventilated discs |
Wheels: Diameter x Width F/R | 17x9/17x11.5in | 18x10.85/18x13in | 18x10.85/18x13in |
Tyres F/R | Goodyear F1, Michelin SX-MXX3 | Michelin | Michelin SX-MXX3 |
Length | 169in/4292mm | 169in/4292mm | 171.8in/4365mm |
Width | 71.6in/1820mm | 71.6in/1820mm | 71.6in/1820mm |
Height | 44.8in/1140mm | 44.8in/1140mm | 44.1in/1120mm |
Wheelbase | 107in/2718mm | 107in/2718mm | 107in/2718mm |
Track F/R | 61.7/58in / 1568/1472mm | 61.3/58.6in / 1558/1488mm | 61.8/57.6in / 1570/1464mm |
Weight | 2502lb/1140kg | 2315lb/1050kg | 2341lb/1062kg |
